Installing Vantech H2.1 Side Access Ladder on RAM ProMaster
|
Posted in Install Videos
For many trades, quick and safe roof access is non-negotiable. That’s why installing Vantech H2.1 Side Access Ladder for the RAM ProMaster is one of our go-to upgrades. In this guide, we’ll walk you through the full installation, highlight key features, and share insider tips to help you get a secure, side-entry ladder mounted in under two hours.
Why Installing Vantech H2.1 Side Access Ladder on RAM ProMaster Matters
First, hauling ladders inside the van takes up valuable space. Furthermore, internal ladder storage can damage gear or walls. Therefore, a side-access ladder frees up your interior. Additionally, it provides quick entry to the roof. As a result, you save time and protect your cargo.
Overview of the Vantech H2.1 Side Access Ladder System
The Vantech H2.1 ladder kit includes:
-
Two mounting uprights designed for ProMaster side rails
-
Three ladder rungs in durable, powder-coated steel
-
Adjustable brackets that align with factory T-bolts
-
All required hardware, including bolts, washers, and lock nuts
Although we don’t manufacture this ladder, we only sell proven brands like Vantech. Consequently, you get reliable, professional-grade performance.
Key Features of the H2.1 Side-Entry Ladder
When you choose the Vantech H2.1, you benefit from:
-
Heavy-Gauge Steel Construction: Supports up to 300 lbs safely
-
UV-Stable Powder Coat: Resists rust, scratches, and weathering
-
Non-Slip Rungs: Textured steps for sure footing in all conditions
-
Low-Profile Design: Minimizes road noise and wind resistance
-
Tool-Free Installation: Uses existing roof rail T-bolts—no drilling
Moreover, the ladder integrates seamlessly with Vantech’s H2.1 cargo racks.
Step-by-Step: Installing Vantech H2.1 Side Access Ladder on RAM ProMaster
-
Bench Prep
First, lay out all components and consult Vantech’s illustrated guide. Next, sort hardware: group large nuts, washers, and lock washers separately. Then, loosely assemble both uprights with top mounting plates.
-
Attach Top Brackets
Next, park the ProMaster on level ground. Meanwhile, slide two T-bolts into the forward roof rail slots. Then, position the top bracket over the T-bolts. Finally, hand-tighten nuts to allow bracket movement.
-
Install Ladder Rungs
Then, attach each rung between the uprights using provided carriage bolts. Meanwhile, ensure the 90° notch faces inward on top and bottom rungs. Afterwards, snug but leave room for adjustment.
-
Mount Bottom Brackets
Afterwards, slide two more T-bolts into rear roof rail slots. Then, align the lower mounting plates over these bolts. Meanwhile, loosely secure hardware, allowing the ladder assembly to pivot.
-
Align and Level
Next, step back and confirm ladder is plumb and parallel with the van’s body lines. Meanwhile, measure equal distances from window trim to top rung on both sides. Finally, adjust brackets before final tightening.
-
Final Torque
Finally, torque top and bottom bracket nuts to 20 ft-lbs per Vantech specifications. Afterwards, tighten carriage bolts on rungs to 15 ft-lbs. Consequently, you achieve a secure, rattle-free ladder.
Pro Tips for Installing Vantech H2.1 Side Access Ladder on RAM ProMaster
-
Use Blue Loctite: Prevents vibration-induced loosening on critical bolts.
-
Work with Doors Closed: Ensures no interference with ladder clearance.
-
Protect the Roof: Place a soft blanket under the assembly to avoid scratches.
-
Test Ladder Fit: Lean your tallest ladder against the rack before final torque.
-
Inspect Annually: Re-check all hardware after the first 1,000 miles.
Moreover, adding reflective tape to rungs boosts nighttime visibility.
Maintenance and Care
After installing Vantech H2.1 Side Access Ladder on RAM ProMaster, keep it in top shape:
-
Wash Monthly: Rinse off salt and road debris to prevent corrosion.
-
Inspect Welds: Check for cracks or paint chips and touch up as needed.
-
Retorque Hardware: Verify torque settings every six months under heavy use.
-
Lubricate Rungs: Apply silicone spray to keep textured steps clear of grime.
These simple steps extend the ladder’s lifespan and reliability.
Elevate Your Van’s Functionality
At Upfit Supply, we know that installing Vantech H2.1 Side Access Ladder on RAM ProMaster delivers unmatched convenience and safety. With rugged steel construction, seamless mounting feet, and quick installation, this side ladder transforms your ProMaster. Ready to streamline roof access? Explore the product and tutorial below:
- Vantech H2.1 Side Access Ladder for RAM ProMaster
- Watch the Tutorial: "Installing Vantech H2.1 Side Access Ladder on RAM ProMaster
With Upfit Supply, you get solutions that work as hard as you do—no exceptions.
