The 5 Best Van Shelving Options for Ford Transit Vans

Shelving is the upgrade that turns a Transit from a cargo box into a workspace. It's also the one people most often order wrong — because a Transit isn't one van. It's three roof heights and three wheelbases, and both of those change what fits.

These are the five we recommend, chosen from what our customers pick most often and what's on the shelf today. Then the part that matters more than the products: how to work out which version fits your van.

Jump to: 1. Folding · 2. Deep 60-in · 3. Standard depth 60-in · 4. Narrow 42-in · 5. Complete package · How to choose · Roof height · Wheelbase · Mounting kits · FAQ

Quick comparison

1. Holman Cargo Van Folding Shelf Kit — 60" W × 20" D

If your unsure what to do for shelving and we could only recommend one shelving product for a work van, this would be it. The shelves fold flat against the wall when you don't need them: organized storage most days, a clear floor between the wheel wells on the day you have to haul something bulky.

Fixed shelving commits that space permanently. If your load varies week to week — and for most trades it does — this is the one that doesn't punish you for it.

Worth knowing: aluminum shelves on steel uprights, so it's lighter than an all-steel unit. Each shelf carries 150 lbs, has a built-in EPDM liner so cargo doesn't slide, and rubber bump stops to stop the rattle you get from folding shelves that aren't well made. The uprights are drilled at multiple heights, and if you run two kits side by side they share the upright between them.

At 20 inches it's also the deepest option here — cases that overhang a 13.5-inch shelf sit properly on this.

Holman Cargo Van Folding Shelf Kit, 60-in W × 20-in D — $1,475.86

Shorter runs: 48-in at $1,362.25 and 36-in at $1,230.71. Note that compact vans don't have the height for two shelves on one upright — those get built from individual parts.

2. Weather Guard Heavy Duty Adjustable 4-Shelf — 60" W × 60" H × 16" D

The heavy duty one, and the fixed shelving unit our customers choose more than any other.

Standard van shelving is 13.5 inches deep. This is 16. That extra two and a half inches sounds marginal until you're holding a bin that hangs over the front edge of a standard shelf.

Two details that separate this from cheap shelving. Captive nuts at every corner — one bolt per corner, and far less of the rattle you get from loose hardware on a work van. And the end panels have notched bases, which leaves floor clearance underneath for a drawer unit or floor-mounted storage rather than wasting that strip.

At 60 inches tall it's a mid and high roof unit only.

Weather Guard Heavy Duty Adjustable 4-Shelf Unit, 60×60×16 (9366-3-03) — $810.00

3. Weather Guard Adjustable 4-Shelf — 60" W × 60" H × 13.5" D

The same unit at standard depth, and the better buy in one specific situation: when you're running shelving on both walls.

Those two and a half inches come off your aisle twice. On a Transit that's the difference between walking down the middle of your van and turning sideways. One wall shelved, take the 16-inch. Both walls, take this.

Weather Guard Adjustable 4-Shelf Unit, 60×60×13.5 (9376-3-03) — $721.00

4. Weather Guard Heavy Duty Adjustable 4-Shelf — 42" W × 60" H × 16" D

Full height, full depth, narrower run — and this is the one we'd put on a 130-inch wheelbase Transit.

On a short Transit a 60-inch run eats most of the wall, and you'll want some of it back for a wheel well, a tank rack, a conduit carrier or just space to turn around. A 42-inch unit gives you the same storage per foot without committing the whole side.

It's also the right call on a longer van when you want shelving and something else on the same wall. Plenty of builds run a 42-inch unit forward and leave the rear half clear.

Same construction as the 60-inch: captive corner nuts, pre-punched accessory holes, four adjustable dividers per shelf.

Weather Guard Heavy Duty Adjustable 4-Shelf Unit, 42×60×16 (9364-3-03) — $652.00

5. Holman Base Shelving Package for Ford Transit

Everything above is a single unit you add to a van. This is the whole interior in one order — shelving, partition and the mounting hardware, specified as a package for your exact Transit.

It's the option we'd point you to if you're outfitting a new van rather than adding to an existing one, or if you're buying for more than one van and want every van laid out identically. Holman's designers build these around input from working trades, so the shelf spacing and configuration start from something sensible rather than a blank wall.

It's also a base, not a finished answer — the whole point is that you add accessories and extra shelving to it. Start here, build on it.

And this is where the Transit's configurations really show. There's a different package for every wheelbase and roof height combination:

Note the pattern: the low roof packages cost around $1,000 less, because a low roof van takes shorter shelving and less of it. Worth knowing before you assume a bigger van is the better value.

How to choose Ford Transit van shelving

Two measurements decide almost everything, and they do different jobs. Roof height decides how tall your shelving can be. Wheelbase decides how long a run you can fit. Both have to match, and most people only think about one.

Roof height decides how tall

The rule worth remembering: a mid roof unit usually fits a high roof, but a low roof needs its own. Shelving doesn't reach the ceiling on a mid or high roof van, so the same 60-inch unit works in both. A low roof genuinely needs a shorter unit.

On a low roof Transit, the unit we'd recommend is the Weather Guard Adjustable 3-Shelf, 42" W × 44" H × 13.5" D at $458.00. At 44 inches tall it fits where a 60-inch unit won't, and it comes with twelve dividers. It's also useful on a taller van under a window or below a long-material run.

This is the opposite of how partitions work. A partition is cut to the roof profile and never interchanges — a mid roof partition will not fit a high roof. Shelving is more forgiving. Don't apply partition logic to shelving or you'll buy twice.

Wheelbase decides how much

Wheelbase doesn't change the height of your shelving. It changes how long a run you can fit along the wall, and therefore which widths make sense.

• 130-in WB — the shortest cargo area. A 42-in unit per side usually makes more sense than a 60-in, leaving room for a tank rack, conduit carrier or just space to move
• 148-in WB — the common work configuration. A 60-in run fits comfortably, or a 42-in plus something else on the same wall
• 148-in Extended — the longest runs. Room to combine fixed shelving up front with folding shelves toward the rear

It also changes the mounting kit, which is where this gets expensive if you don't plan for it.

The mounting kit is specific to both

Individual shelving units can bolt straight to the van, but a mounting kit is a game changer. With a van shelf mounting kit you can easily make adjustments without having to redrill into your van until you get your shelves where you want them to be. Be sure to check these mounting kits out as most of them are sold separately and there's a different part number for every combination of roof height and wheelbase.

Five different part numbers for one model of van. Budget $280 to $360 on top of the shelving. This is the single most common reason a shelving order gets held up and it's one of the arguments for a complete package, which comes with its mounting hardware included.

Depth: 13.5 or 16 inches

Measure a bin you actually use before deciding. If your standard tote overhangs a 13.5-inch shelf, go to 16. If you're shelving both walls, stay at 13.5 and keep your aisle.

One thing to expect either way: the top shelf is always shallower than the rest. A 16-inch unit has a 13.5-inch top shelf; a 13.5-inch unit has a 10.5-inch top. That's because quality van shelving has tapered end panels that follow the inward slope of the van wall, so the unit sits tight against it rather than leaning out into your aisle. It's standard across the good brands, and it's why the top shelf is best used for lighter, smaller items.

Steel or aluminum

Steel costs less and takes more abuse — the right call for plumbing, heavy mechanical, and anything where the van gets used hard.

Aluminum is significantly lighter, and that matters more than people expect. A full steel build on both walls is real weight on a van that also has to carry your tools and inventory. If you're anywhere near your payload, aluminum buys it back. The Holman folding kit splits the difference — aluminum shelves on steel uprights.

Fixed, folding, or a complete package

Fixed gives you more total storage and costs less per unit. Folding gives you a flat floor on demand. A complete package costs more up front but arrives as a designed interior with the mounting hardware included, which is the sensible route for a new van or a fleet order.

Dividers and accessories

Check what's included. The Weather Guard units come with four adjustable dividers per shelf, which is what stops small parts migrating across the shelf on every corner. They also have pre-punched accessory holes, so adding hooks, holders or back panels later doesn't mean drilling.

Build order

If you're outfitting a Transit from scratch, shelving isn't step one. Put the floor in first — shelving anchors to it, and retrofitting a floor under installed shelving means taking the shelving out. Then the partition, which sets your usable cargo length. Then liners, which mount to bare metal. Shelving comes fourth.

FAQ

Will mid roof shelving fit a high roof Transit?
Usually yes. Most Transit shelving doesn't reach the ceiling on either, so a 60-inch unit works in both. Check the product listing for mid/high roof fitment.

Will mid or high roof shelving fit a low roof Transit?
No. A low roof Transit has roughly 56.9 inches of interior height and a 60-inch unit won't fit. You need 44-inch shelving.

Does wheelbase change which shelving I need?
It changes how long a run you can fit and which mounting kit you need, not the height of the units. On a 130-inch wheelbase a 42-inch unit usually makes more sense than a 60-inch.

Do I need a mounting kit?
For individual shelving units, it's recommended, and it's sold separately — a different part number for each combination of roof height and wheelbase, five of them for the Transit alone. Complete shelving packages include their mounting hardware.

Is a shelving package better value than buying units separately?
It depends what you're doing. Individual units are cheaper if you're adding to an existing build or only need one wall. A package makes more sense for a new van or a fleet, because it arrives designed, includes the mounting hardware, and every van ends up laid out the same.

Why is the top shelf shallower than the others?
Because the end panels are tapered to follow the inward slope of the van wall. That lets the unit sit tight against the wall instead of leaning into your aisle. It's standard on quality van shelving, and the top shelf is best used for lighter items.

Should I get 13.5-inch or 16-inch deep shelving?
16-inch if bins and cases overhang a standard shelf. 13.5-inch if you're shelving both walls and need the aisle.

Steel or aluminum van shelving?
Steel for abuse resistance and lower cost. Aluminum to protect payload, which matters on a van already carrying a full load of tools.

Can I mix folding and fixed shelving?
Yes, and it's a common setup — fixed up front where the load doesn't change, folding toward the rear where you sometimes need the floor.

How much does a full Transit shelving build weigh?
More than most people expect. Steel shelving on both walls is one of the heaviest items in a typical upfit, and it comes out of the same payload budget as your tools. Weigh the van before committing to a full steel build.

Not sure what fits? Tell us your roof height and wheelbase and we'll confirm the shelving and the mounting kit together — it's a two-minute check that saves the most common ordering mistake on this vehicle.
