Ford Transit (148 Extended WB) Interior Cargo Measurements

Last updated

|

Posted in Measurement Guides

Download Diagram As PDF

Use the diagram above and chart below to find interior dimensions for the Ford Transit cargo van with 148-inch extended wheelbase. The primary difference between the 148 REGULAR and 148 EXTENDED vans is the 148 EXTENDED is about 28-inches longer behind the rear wheels. The EXTENDED body is only offered in the high roof configuration, so if you have a mid- or low-roof, you do not have the EXTENDED body. This guide is useful when looking to install van shelving and other cargo van equipment in your Ford Transit.

Description Measurement
Partition Depth 9"
Inside Roof Height 79" (HR)
Wall Space Width for Shelving - Driver Side 136"-145"
Wall Space Width for Shelving - Passenger Side 103"
Door Opening Width - Side 36"
Door Opening Width - Rear 53"
Wheel Well Dimensions 35" W x 11" H x 8" D (SRW)
Distance Between Wheel Wells 52" (SRW); 44" (DRW)

The measurements provided on this page apply to the following model year vehicles:

  • 2015 Ford Transit-350 HD (148" WB - extended body length)
  • 2016 Ford Transit-350 HD (148" WB - extended body length)
  • 2017 Ford Transit-350 HD(148" WB - extended body length)
  • 2018 Ford Transit-350 HD (148" WB - extended body length)
  • 2019 Ford Transit-350 HD (148" WB - extended body length)
  • 2020 Ford Transit-350 HD (148" WB - extended body length)
  • 2021 Ford Transit-350 HD (148" WB - extended body length)
  • 2022 Ford Transit-350 HD (148" WB - extended body length)
  • 2023 Ford Transit-350 HD (148" WB - extended body length)
  • 2024 Ford Transit-350 HD (148" WB - extended body length)
