SpitzLift Service Body Crane - Enclosed Service Body - Low/Mid Roof - Rear Door

The SpitzLift Low Profile Crane is the perfect lifting solution for enclosed service bodies with low to medium roof heights (49–57 inches). This compact yet powerful crane installs cleanly inside your vehicle and delivers a 900 lb lifting capacity—ideal for safely loading compressors, toolboxes, and other heavy equipment while preserving valuable floor space and vehicle payload.

Key Features:

• Optimized for Low/Medium Roofs: Designed to fit door openings between 49 and 57 inches (124.5 – 144.8 cm), making it ideal for enclosed utility/service bodies with height constraints.
• High Lifting Capacity: Handles up to 900 lbs (408.2 kg) while maintaining a lightweight crane body at just 36 lbs (16.3 kg).
• Efficient Installation: Fully installed system adds less than 100 lbs to your vehicle’s payload, preserving work vehicle efficiency.
• 360° Continuous Rotation: Smooth, full-circle operation allows you to lift and position loads with ease.
• Durable Construction: Built from aircraft-grade aluminum and steel, and finished with clear anodizing and powder coating for corrosion resistance and long-lasting performance.
• Powered Hoist Operation: Features the SpitzLift LTD-324 12V DC hoist with pendant controller, quick DC connect, and wiring harness for reliable electric lifting.
• Made in the USA: Designed, manufactured, and assembled in the United States.

Specifications:

• Door Opening Range: 49–57 inches (124.5 – 144.8 cm)
• Max Lifting Capacity: 900 lbs (408.2 kg)
• Crane Weight: 36 lbs (16.3 kg)
• Installed Weight: Approx. 65 lbs (29.5 kg)
• Rotation: 360° continuous
• Materials: Aircraft-grade aluminum and steel
• Power Requirements: 12V DC with wiring harness and quick-connect

Included Components:

• 3 ft SpitzLift DC-powered crane (Model LTD-324)
• Pedestal mount (KESB-010)
• Reinforcement installation kit
• DC pendant controller and wiring harness

The SpitzLift Low/Medium Roof Enclosed Service Body Crane delivers unmatched versatility and lifting power in a compact, low-profile package. Whether you need a permanent setup or a removable option, this USA-made crane is trusted by fleets, contractors, and service professionals nationwide.
