Ford Transit (130 WB) Interior Cargo Measurements

Last updated September 26, 2025

Tags: Ford Measurement Guides Transit

Use the diagram above and chart below to find interior dimensions for the Ford Transit cargo van with 130-inch wheelbase. This guide is useful when looking to install van shelving and other cargo van equipment in your Ford Transit.

Description	Measurement
Partition Depth	9"
Inside Roof Height	53" (LR); 70" (MR)
Wall Space Width for Shelving - Driver Side	92"-101"
Wall Space Width for Shelving - Passenger Side	58"
Door Opening Width - Side	36"
Door Opening Width - Rear	53"
Wheel Well Dimensions	35" W x 11" H x 8" D
Distance Between Wheel Wells	53"

The measurements provided on this page apply to the following model year vehicles:

2015 Ford Transit-150 (130" WB)
2016 Ford Transit-150 (130" WB)
2017 Ford Transit-150 (130" WB)
2018 Ford Transit-150 (130" WB)
2019 Ford Transit-150 (130" WB)
2020 Ford Transit-150 (130" WB)
2021 Ford Transit-150 (130" WB)
2022 Ford Transit-150 (130" WB)
2023 Ford Transit-150 (130" WB)
2024 Ford Transit-150 (130" WB)
2015 Ford Transit-250 (130" WB)
2016 Ford Transit-250 (130" WB)
2017 Ford Transit-250 (130" WB)
2018 Ford Transit-250 (130" WB)
2019 Ford Transit-250 (130" WB)
2020 Ford Transit-250 (130" WB)
2021 Ford Transit-250 (130" WB)
2022 Ford Transit-250 (130" WB)
2023 Ford Transit-250 (130" WB)
2024 Ford Transit-250 (130" WB)
2015 Ford Transit-350 (130" WB)
2016 Ford Transit-350 (130" WB)
2017 Ford Transit-350 (130" WB)
2018 Ford Transit-350 (130" WB)
2019 Ford Transit-350 (130" WB)
2020 Ford Transit-350 (130" WB)
2021 Ford Transit-350 (130" WB)
2022 Ford Transit-350 (130" WB)
2023 Ford Transit-350 (130" WB)
2024 Ford Transit-350 (130" WB)
